Features
- Prints more labels every second, with 5 inches/sec speed
- Connects with any possible machine with USB, standard parallel or serial ports
- Prints any size of label with its movable black
- Larger print width supports up to 4 inch wide labels
- High memory space of 8 MB FLASH RAM and 64 MB SDRAM, supports pre-loaded fonts and table formats for quick printing
SPECIFICATIONS
| Resolution | 203 DPI |
| Printing Method | Thermal/Thermal transfer |
| Max. Print width | 104 mm |
| Max. Print speed | 125 mm/s |
| CPU | 32bit RISC micro-processor |
| Memory | 8 MB FLASH RAM I 64 MB SDRAM |
| THP temperature detection | Thermistor |
| THP position detection | Micro-switch |
| Paper mark detection | Optical sensor |
| Ribbon detection | Optical sensor |
| Interface | Standard configuration: RS-232 Serial, CENTRONICS Parallel, USB |
| Driver | Windows driver (98/2000/XP/Win 7/Win 8 [32-bit, 64-bit]) |
| Barcode | 1D barcode Code 3 of 9, UPCA, UPCE, Interleaved 2 of 5, code 128, EAN13, EAN8, HBIC (39 code with checkout) |
| Fonts | Coda bar, industry CODE 25, Checksum & shipping bearer bars |
| Graphics | UPC2, UPC5, Code 93, POSTNET 25 (China), UCC/EAN, Matrix 25, POSTNET code, etc. |
| 2D barcode | PDF417, MAXICODE, OR code etc. |
| Common single-byte font | FONTO to FONTS, 6 kinds of ASD smooth font, 8 kinds of Courier font |
| Self-defined font | Users can define the font and download to FLASH or SDRAM |
| Rotation print | 0°, 90°, 180°, 270° |
| Graphics | Binary plain graphics, HEX, PCX, BMP and IMG graphics can be downloaded to FLASH/RAM |
| Paper type | Continuous paper, label paper, marked paper, perforated paper |
| Paper rolls 0/D (Max) | 127 mm, ID 25mm, width (Max): 118 mm |
| Ribbon length (Max) | 300 m, OD 25 mm |
| Input | AC 110-240 V, 50/60 Hz |
| Output | DC 24 V, 1.5A & DC 24 V, 2.5 A |
| Operation environment | +5-45°, 20%-90% (40°C) |
| Storage environment | -40-60°, 20%-93% (40°C) |
| Overall size | 300 mm (L) x252 mm (W) x190 mm (H) |
| Weight | About 3.5 Kg |
| a. TPH | 30 Km or 12 Months (from delivery) which comes first |
| b. Platen | 50 Km (Service part) |
