Chipset

INTEL B760

CPU

Support: Intel® Core™ 14th/ 13th/ 12th Gen Processors, Intel® Pentium® Gold and Celeron® Processors

Socket: LGA 1700

Memory

Slots: 4x DDR5, Maximum Capacity 256GB

Supported Frequencies: DDR5 6800+(OC)/ 6600(OC)/ 6400(OC)/ 6200(OC)/ 6000(OC)/ 5800(OC)/ 5600(JEDEC)/ 5400(JEDEC)/ 5200(JEDEC)/ 5000(JEDEC)/ 4800(JEDEC) MHz

Max. Overclocking Frequency:

• 1DPC 1R Max speed up to 6800+ MHz
• 1DPC 2R Max speed up to 6400+ MHz
• 2DPC 1R Max speed up to 6000+ MHz
• 2DPC 2R Max speed up to 5600+ MHz

Features:

• Supports Intel® XMP 3.0 OC
• Supports Dual-Controller Dual-Channel mode
• Supports non-ECC, un-buffered memory

Onboard Graphics

• 2x HDMI™ – HDMI 2.1, max resolution 4K 60Hz*
• 2x DisplayPort – DP 1.4, max resolution 4K 60Hz*

*Available only on processors featuring integrated graphics. Graphics specifications may vary depending on the CPU installed.

Slots

• 2x PCI-E x16 slots
• 1x PCI-E x1 slot

• PCI_E1 Gen PCIe 4.0 supports up to x16 (From CPU)
• PCI_E2 Gen PCIe 3.0 supports up to x1 (From Chipset)
• PCI_E3 Gen PCIe 4.0 supports up to x4 (From Chipset)

Audio

Codec: Realtek® ALC897

7.1-Channel High Definition Audio

Storage

• 2x M.2:
  • M.2_1 (From CPU): PCIe 4.0 x4, 2280/2260/2242
  • M.2_2 (From Chipset): PCIe 4.0 x4 / SATA, 2280/2260/2242
• 4x SATA 6G

* SATA8 will be unavailable when installing M.2 SATA SSD in the M2_2 slot.

RAID

Supports RAID 0, 1, 5, and 10 for SATA devices

USB

• 2x USB 2.0 (Rear)
• 4x USB 2.0 (Front)
• 2x USB 5Gbps Type A (Rear)
• 4x USB 5Gbps Type A (Front)
• 1x USB 5Gbps Type C (Front)
• 2x USB 10Gbps Type A (Rear)

LAN

Chip: Realtek® RTL8125BG 2.5G LAN

Internal IO

• 1x ATX_PWR
• 2x CPU_PWR
• 1x CPU Fan
• 1x Pump Fan
• 2x System Fan
• 2x Front Panel (JFP)
• 1x Chassis Intrusion (JCI)
• 1x Front Audio (JAUD)
• 1x Com Port (JCOM)
• 2x Addressable V2 RGB LED (JARGB_V2)
• 1x RGB LED (JRGB)
• 1x TPM Header (TPM 2.0)
• 4x USB 2.0 ports
• 4x USB 5Gbps Type A ports
• 1x USB 5Gbps Type C port

Wireless LAN & Bluetooth

Chipset: Intel® Wi-Fi 6E

The Wireless module is pre-installed in the M.2 (Key-E) slot

Wi-Fi: MU-MIMO TX/RX, 2.4GHz / 5GHz / 6GHz* (160MHz) up to 2.4Gbps

Standards: 802.11 a/ b/ g/ n/ ac/ ax

Bluetooth: 5.3, FIPS, FISMA

* Wi-Fi 6E 6GHz may depend on regional regulations and requires Windows 11.
** Bluetooth 5.3 is supported on Windows 10 build 21H1 and Windows 11.

LED Feature

4x EZ Debug LED
