Mid Tower

Legacy

Cases

• I/O Panel: 2x USB 2.0
• Expansion Slots: 7
• Motherboard Support: ATX
• Series: Elite Series
• Power Supply Support: Standard ATX PS2 (optional)

Cooling System

• Rear: 120 x 25mm fan x 1 / 1200 RPM / 17 dBA (installed)
• Side: 1x 80/90/120mm fan (optional)
• Rear (alternative): 80/90mm fan x 1 (optional)
• Front: 120 x 25 mm fan x 1 (optional)

Maximum Compatibility

• VGA Card Length: 275mm / 10.8 inch
• CPU Cooler Height: 155mm / 6.1 inch

Motherboard Support

• Micro ATX

Drive Bays

• 3.5" Drive Bays (hidden): 6
• 5.25" Drive Bays (exposed): 4
• 3.5" Drive Bays (exposed): 1

I/O Panel

• 1x Mic
• 1x Audio (supports HD audio)
• IEEE 1394a (optional)

Materials

• Steel body
• ABS plastic front bezel

Color(s)

• Orange, Blue, Silver/Black
• Blue, Pink/White

Weight

• Gross Weight: 6.9 kg / 15.2 lbs
• Net Weight: 5.8kg / 12.8 lbs

Dimensions

• 191 x 437 x 468 mm / 7.5 x 17.2 x 18.4 inch

Model Number

• RC-310
