| Output |
| Max Configurable Power (Watts) 1.2kWatts / 2.2kVA |
| Output Frequency (sync to mains) 50/60 Hz +/- 1 Hz Unsynchronised |
| Other Output Voltages 230 V |
| Topology Line interactive |
| Waveform type Stepped approximation to a sinewave |
| 10 ms maximum |
| Input |
| Input frequency 40 - 70 Hz +/- 5 Hz Auto-sensing |
| Input voltage range for main operations 140 - 300V |
| Number of Power Cords 1 |
| Type of Input Protection Required Circuit breaker |
| Batteries & Runtime |
| Battery type Lead-acid battery |
| Typical recharge time 6hour(s) |
| Nominal Battery Voltage 24 V |
| Battery Volt-Amp-Hour Capacity 216 |
| Communications & Management |
| on battery : replace battery and overload indicators |
| distinctive low battery alarm : overload continuous tone alarm |
| Surge Protection and Filtering |
| Surge energy rating 255Joules |
| Physical |
| Maximum Height 190MM, 19.0CM |
| Maximum Width 140MM, 14.0CM |
| Maximum Depth 390MM, 39.0CM |
| Net Weight 12.2KG |
| Shipping weight 13.2KG |
| Shipping Height 297MM, 29.7CM |
| Shipping Width 235MM, 23.5CM |
| Shipping Depth 495MM, 49.5CM |
| Color Black |
| Environmental |
| Operating Temperature 0 - 40 °C |
| Operating Relative Humidity 0 - 95 (Non-condensing) % |
| Operating Elevation 0 - 3000meters |
| Storage Temperature -20 - 50 °C |
| Storage Relative Humidity 0 - 95 (Non-condensing) % |
| Storage Elevation 0 - 15000meters |
| Audible noise at 1 meter from surface of unit 40.0dBA |
| Protection Class IP20 |
| Conformance |
| Approvals BIS |
